**THIS IS THE SPECIFICATION FOR THE CELLULAR (SIM)-VERSION, PLEASE SCROLL FURTHER DOWN FOR THE WIFI-VERSION’S SPECIFICATIONS

NETWORK	Technology	GSM / HSPA / LTE



LAUNCH	Announced	2014, June. Released 2014, July
	Status	Discontinued



BODY	Dimensions	247.3 x 177.3 x 6.6 mm (9.74 x 6.98 x 0.26 in)
	Weight	467 g (1.03 lb)
	SIM	Micro-SIM



DISPLAY	Type	Super AMOLED
	Size	10.5 inches, 319.7 cm2 (~72.9% screen-to-body ratio)
	Resolution	2560 x 1600 pixels, 16:10 ratio (~288 ppi density)



PLATFORM	OS	Android 4.4.2 (KitKat), upgradable to 6.0 (Marshmallow), TouchWiz UI
	Chipset	Qualcomm Snapdragon 800 (28 nm) Exynos 5420 Octa (28 nm)
	CPU	Quad-core 2.3 GHz Krait 400 (S800) Quad-core 1.9GHz Cortex-A15 & quad-core 1.3 GHz Cortex-A7 (Exynos 5420)
	GPU	Adreno 330 (S800) Mali-T628MP6 (Exynos 5420)



MEMORY	Card slot	microSDXC (dedicated slot)
	Internal	16GB 3GB RAM, 32GB 3GB RAM
		eMMC 4.5



MAIN CAMERA	Single	8 MP, AF
	Features	LED flash, panorama, HDR
	Video	1080p@30fps



SELFIE CAMERA	Single	2.1 MP
	Video



SOUND	Loudspeaker	Yes, with stereo speakers
	3.5mm jack	Yes



COMMS	WLAN	Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, hotspot
	Bluetooth	4.0, A2DP, LE
	GPS	Yes, with A-GPS, GLONASS, BDS
	NFC	No
	Infrared port	Yes
	Radio	No
	USB	microUSB 2.0 (MHL 2.1), USB On-The-Go



FEATURES	Sensors	Fingerprint (front-mounted), accelerometer, gyro, compass



BATTERY	Type	Li-Ion 7900 mAh, non-removable
	Talk time	Up to 11 h (multimedia) (2G) / Up to 48 h (3G)
	Music play	Up to 132 h



MISC	Colors	Dazzling White, Titanium Bronze
	Models	SM-T805
	SAR	1.59 W/kg (body)
	SAR EU	0.90 W/kg (body)



TESTS	Display	Contrast ratio: Infinite (nominal)
	Loudspeaker	Voice 70dB / Noise 65dB / Ring 75dB
	Audio quality	Noise -95.8dB / Crosstalk -96.4dB



**THIS IS THE SPECIFICATION FOR THE WIFI-VERSION, PLEASE SCROLL BACK UP FOR THE CELLULAR (SIM)-VERSION’S SPECIFICATIONS

NETWORK	Technology	No cellular connectivity



LAUNCH	Announced	2014, June. Released 2014, July
	Status	Discontinued



BODY	Dimensions	247.3 x 177.3 x 6.6 mm (9.74 x 6.98 x 0.26 in)
	Weight	465 g (1.03 lb)
	SIM	No



DISPLAY	Type	Super AMOLED
	Size	10.5 inches, 319.7 cm2 (~72.9% screen-to-body ratio)
	Resolution	2560 x 1600 pixels, 16:10 ratio (~288 ppi density)



PLATFORM	OS	Android 4.4.2 (KitKat), upgradable to 6.0.1 (Marshmallow), TouchWiz UI
	Chipset	Exynos 5420 Octa (28 nm)
	CPU	Octa-core (4×1.9 GHz Cortex-A15 & 4×1.3 GHz Cortex-A7)
	GPU	Mali-T628 MP6



MEMORY	Card slot	microSDXC (dedicated slot)
	Internal	16GB 3GB RAM, 32GB 3GB RAM



MAIN CAMERA	Single	8 MP, AF
	Features	LED flash, panorama, HDR
	Video	1080p@30fps



SELFIE CAMERA	Single	2.1 MP
	Video



SOUND	Loudspeaker	Yes, with stereo speakers
	3.5mm jack	Yes



COMMS	WLAN	Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, hotspot
	Bluetooth	4.0, A2DP, LE
	GPS	Yes, GLONASS, BDS
	NFC	No
	Infrared port	Yes
	Radio	No
	USB	microUSB 2.0 (MHL 2.1), USB On-The-Go



FEATURES	Sensors	Fingerprint (front-mounted), accelerometer, gyro, compass



BATTERY	Type	Li-Ion 7900 mAh, non-removable
	Talk time	Up to 11 h (multimedia)
	Music play	Up to 121 h



MISC	Colors	Dazzling White, Titanium Bronze
	Models	SM-T800
	SAR	0.77 W/kg (body)
	SAR EU	0.20 W/kg (body)



TESTS	Performance	Basemark X: 6875
	Display	Contrast ratio: Infinite (nominal)
	Camera	Photo / Video
	Loudspeaker	Voice 70dB / Noise 65dB / Ring 75dB
	Audio quality	Noise -95.8dB / Crosstalk -96.4dB
